The Next Generation of 2-IN-1 High Precision Power Monitoring Hardware and Benchtop Power Supply is here


  Eliminate the need to buy a separate power supply and power monitoring device. Save space and
test setup cost using the highly scalable solution of Monsoon High Voltage Power Monitor (HVPM).


BRIEF SPECIFICATIONS TYPICAL USE CASES WHAT’S INCLUDED?
• Size: 8 in x 6 in x 2 in (20 cm x 15 cm
x 5 cm)

• Weight: 1.1 lb (0.5kg)
• Input power 115V to 240V, 47-63Hz
• Main channel 0.8V to 13.5V range
• USB channel 2.1V to 5.4V
• Aux channel input 0.5V to 13V
• UL, CE, FCC certified

• Smartphones, Tablets or Laptops
• Smartphone Apps
• Internet of Things (IoT) Devices,
Medical Devices
• USB Devices
• Automotive Sub-circuits
• Prototype Designs
• Power measurement of Arduinos,  Raspberry Pi and Microcontrollers
• Burn in testing
• High Voltage Power Monitor (HVPM)
• Power supply
• 2 alligator clips
• 2 USB cables
• Information card with links to PowerTool software
