The TRACE32 is a modular development system which can be easily adapted to different microprocessors and customer needs. To ensure transparent support for all types of emulation probes, the system was developed using a 'top-down' approach with the high speed, 32 bit emulation modules being developed first, followed by 16 bit and then 8 bit. As a result, the same base system can, for example, support an 8051 or a PowerPC. The TRACE32 system concept is long term, in line with Lauterbach's long term commitment to continue to provide its customers with the most advanced tools available. Lauterbach's belief in 'open systems' is self evident, with support for over 300 microprocessors, 60 different compilers, 6 programming languages, 15 host operating systems and 10 multitasking RTOS kernels. They also believe that the High Level Debugger must be an integral part of the MDS to allow high speed debugging and access to all features of the emulator and it is their declared aim to provide software engineers with a debug workstation, not just an emulator as a back-end to software tools. A high speed ETHERNET interface to their 32-bit based system controller with additional communications processors, gives TRACE32 the highest download and system performance available anywhere and allows development teams to work across the world using the INTERNET.





  JTAG Debuggers

  Power Debug USB3


The Lauterbach product TRACE32-ICD supports a wide range of on-chip debug interfaces. The hardware for the debugger is universal and allows interfacing different target processors by simply changing the debug cable and the software.






  • Support for a wide range of on-chip debug interfaces
  • Easy high-level and assembler debugging
  • Interface to all compilers
  • Fast download
  • RTOS awareness
  • Interface to all hosts
  • Display of internal and external peripherals at a logical level
  • Flash programming
  • Hardware breakpoints and trigger (if supported by chip)
  • Multiprocessor/multicore debugging
  • Software trace
  • Virtual analyzer
  • USB 3 Interface


  Power Debug Ethernet


The Lauterbach product TRACE32-ICD supports a wide range of on-chip debug interfaces. The hardware for the debugger is universal and allows to interface different target processors by simply changing the debug cable and the software. PowerDebug Ethernet can be upgraded to PowerTrace.






  • Support for a wide range of on-chip debug interfaces
  • Easy high-level and assembler debugging
  • Interface to all compilers
  • Fast download
  • RTOS awareness
  • Interface to all hosts
  • Display of internal and external peripherals at a logical level
  • Flash programming
  • Hardware breakpoints and trigger (if supported by chip)
  • Upgradable to PowerTrace
  • Multiprocessor/multicore debugging
  • Software trace
  • Virtual analyzer
  • USB 2 and 100 MBit Ethernet Interface




  µtrace for Cortex-M


A new all-in-one debug and trace solution has been developed by Lauterbach in response to the breakthrough of Cortex-M processors into the embedded market. This lower cost system called µTrace specifically targets the Cortex-M family.






  • Support for more than 1000 different Cortex-M based chips
  • Easy high-level and assembler debugging
  • USB 3 interface
  • Support for standard JTAG, Serial Wire Debug, and cJTAG (IEEE 1149.7)
  • 256MByte trace memory
  • 10/20/34-pin half-size connector for target hardware and adapters for a wide variety of other connectors
  • Voltage range 0.3V to 3.3V (5V tolerant inputs)
